Application
Designed for use on crossings and switch points on rails over 42kg/m.
The jack is obstruction less.
| Code | Description | Weight |
| 10-034 | Hydraulic Toe Jack Type B | 18.5kg |
| 10-041 | Hydraulic Toe Jack Type C | 36kg |
| Specification Hydraulic Toe Jack Type B |
| Safe working load: 8t on head / 5t on toe Closed height: 235mm head / 95mm toe Toe to head: 140mm Lifting stroke: 90mm |
| Specification Hydraulic Toe Jack Type C |
| Safe working load: 20t on head / 15t on toe Closed height: 343mm head / 191mm toe Toe to head: 152mm Lifting stroke: 110mm |
